Cartoner

Main function

The cartoner is an automated secondary packaging machine that takes flat cartons (“blanks”) and sequentially performs carton forming, product loading, and carton closing/sealing operations in order to produce a final package ready for shipment or downstream operations. It can be configured in horizontal mode (side product loading) or vertical mode (top loading) and may be manual, semi-automatic, or fully automatic depending on the desired level of integration.

Typical applications

The cartoner integrates into production lines where rigid carton packaging is required after primary processes (filling, sealing, inspection):
· Secondary packaging of wrapped products (e.g., flow wrap, pouches, jars, trays) into rigid cartons
· Packaging on high-speed automated lines with upstream and downstream synchronization
· Multi-format and multi-lane applications using adapted feeding and infeed systems
· Usage configurations:
· Horizontal cartoner for side-loaded products
· Vertical/top-load cartoner for sensitive products or top-loaded applications

Key benefits

· Fully automated or modular operation: Semi-automatic to fully automated operation options, including integrated “Form-Pack-Seal” systems for continuous lines.
· High format flexibility: Design adaptable to various carton sizes, with fast format changeover to reduce downtime.
· High and efficient production speeds: Machines capable of reaching competitive industrial speeds (e.g., up to 320 cpm depending on configuration).
· Operational reliability: Mechanical architecture and PLC control designed for multi-shift industrial environments.
· Ergonomic and user-friendly integration: Intuitive HMI interfaces, easy adjustments, and machine safety compliant with industrial standards.

Technical specifications

  • Technologies Horizontal cartoner, vertical (top load), semi-automatic or fully automatic depending on application
  • Integrated brands Multi-supplier solutions based on product type, throughput, and automation level required
  • Frame Industrial painted steel or stainless steel construction depending on production environment
  • Throughput Variable depending on format and configuration, suitable for medium to high-speed production lines
  • Control & Automation PLC / HMI, servo axes, integrated diagnostics, product recipes, upstream / downstream synchronization
  • Options disponibles Robotic loading, hot-melt sealing, tuck-in closure, lot/date printing, quality vision, quick changeover, multi-lane setups

Solutions tailored to your operations

Benefit from Storcan’s expertise to design a high-performance, scalable production line.
