Hytrol Belt Conveyors for cases, boxes and parcel
Main function
The Hytrol SB-RB-TA / SBI-RBI belt conveyor provides continuous and controlled transport of unit loads, cartons, containers, or various products using a conveyor belt supported either by a slider bed or a roller bed.
The belt conveying surface provides uniform product support, improves flow control, and allows better traction for horizontal, inclined, or declined applications. Belt-over conveyors are designed to provide a high level of product control while adapting to a wide range of industrial environments.
The models are available in several configurations:
• SB / TA / SBI → slider bed version
• RB / RBI → roller bed version (for heavier loads)
• SBI / RBI → inclined or declined versions
Typical applications
• Conveying cartons, containers, packaged goods, or manufactured parts
• Assembly, inspection, and packaging lines
• Product transfer between automated stations
• Applications requiring precise product flow control
• Horizontal, inclined, or declined conveying
• Conveying within distribution or internal logistics systems
• “Booster” conveyors within gravity conveyor systems
Belt-over conveyors are typically used when powered roller conveyors are not suitable, particularly when the product requires better support or increased traction.
Key benefits
• Superior product control: The continuous belt surface provides uniform product support, allowing stable and precise conveying even for irregular or sensitive products.
• High installation versatility: Conveyors can be configured for horizontal, inclined, or combined transport, allowing optimization of material flow and production line layout.
• Adaptability to various load types
Slider bed version: ideal for light to medium loads
Roller bed version: enables heavier load transport by reducing friction between the belt and support surface.
• Smooth and quiet operation: The mechanical design reduces vibration and noise, minimizing product damage risk while improving the working environment.
• Simplified maintenance: The modular design provides quick access to components, facilitating maintenance and reducing downtime.
• Reversible operation and operational flexibility: Conveyors can operate in both directions and adapt easily to production flow changes.
• Efficient performance for inclined conveying: SBI and RBI models allow smooth transitions between inclined and horizontal sections thanks to adjustable nose-over transitions.
Technical specifications
- Frame Formed painted steel industrial structure with bolted supports, designed for manufacturing and logistics environments
- Belt PVC, nitrile, or industrial polyester belt on slider bed or roller bed depending on application
- Drive System AC gearmotor with center drive, fixed or variable speed depending on configuration
- Components Drive pulleys, mechanical belt tensioning system, support rollers, side guides, conveyor modules
- Available Options Horizontal, inclined, or declined configurations, variable speed drive, specialty belts, ceiling/floor supports, guarding
